3D Dynamic Focusing Co2 Laser Marking Machine

  • 3D Dynamic Focusing Co2 Laser Marking Machine
  • 3D Dynamic Focusing Co2 Laser Marking Machine
  • 3D Dynamic Focusing Co2 Laser Marking Machine
  • 3D Dynamic Focusing Co2 Laser Marking Machine

3D Dynamic Focusing Co2 Laser Marking Machine

    Payment Type: L/C,T/T
    Terms of Trade: FOB,EXW
    Min. Order: 1 Set/Sets
    Delivery Time: 15 Days
    Packaging: Wooden Package
    Productivity: 100 sets per month
    Brand: VMADE
    Transportation: Ocean
    Place of Origin: Jinan, Shandong
    Certificate: CE
    HS Code: 8456110090
    Port: Qingddao

Basic Info

Model No.: VLC100W

Product Description

3D Dynamic Focusing Co2 Laser Marking Machine

Product Description

Advantages
1.A larger range and finer light effects.
3D marking using pre-focused optical mode, the use of larger X, Y-axis deflection lens, which can allow the transmission of laser light spot larger, better focusing accuracy, energy better; if 3D marking with 2D marking in The same focus precision work, the marking range can be greater.

2.You can mark a different height of the object, variable focal length changes more.
As the 3D marking can quickly change the laser focal length and laser beam position, so the previous 2D can not achieve the surface marking possible. After using 3D, a certain degree of curvature within the cylinder marking can be completed, greatly improving the processing efficiency. Moreover, in real life, many parts of the surface shape is not regular, and some parts of the surface height difference is quite large, for 2D marking processing is really powerless, and this time, the advantages of 3D marking will become more obvious.

3. More suitable for deep carving.
Traditional 2D marking on the surface of the deep shadow of the existing defects, with the carving process of laser focus on the move, the role of the actual surface of the laser energy will be a sharp decline, seriously affecting the effect and efficiency of deep carving.

For the traditional deep carving practice is the electric way in the carving process at regular intervals to move the lift to a certain height to ensure that the laser surface is well focused. 3D marking for deep processing, there is no such problem, both to ensure the effect, but also improve the efficiency, while Eliminating the cost of electric lift.

Features
1.Unique optical path design based on laser beam characteristics, low optical loss with 20% efficiency increased.

2.Rapid response with high speed THK guide rail of Z axis.

3.High stability with CTI servo motor galvanometer.

4.Original USA coherent CO2 laser tube with long working lifetime,is characterized by large power, high-quality light spot, excellent performance, stable power and long service life(20k hours).

5.Tiny beam spot , making more precision.

6.Full sealed and maintenance-free laser optic system which key components all imported from USA or UK, realizes usage at installation without adjustment.

7.The 3 axis laser scanning system features compact construction, dust-proof, convenient and accurate installation, strong anti-jamming ability, etc.

8.The heat elimination method of the scanning motor and the drive board has been taken into full consideration during the design of the system, so as to ensure the stability of the system under long-hours working condition.

9.High-precision and high-speed marking/cutting, efficiency is 20% higher than other similar models.

10.This equipment can run more stably and with even longer service life by utilizing water cooling on both the RF laser and extender lens.

11.USB interface bus has been adopted for the control card, which supports offline operation, stepper motor with X, Y, Z and R axis (X, Y and Z axis linked.), support start-up and stopping marking by external control.

12.Rotary worktable system is optional, thus, accomplish marking on cambered surface.

13.Strong graphics drawing and editing functions enable direct marking of color graphic or marking after color convert from RGB to grey scale.

14.Under WINDOWS interface, compatible with files outputted from software such as CORELDRAW, AUTOCAD, PHOTOSHOP etc. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font.

15.Industrial computer support Windows 7, XP or 10.

16.Strong anti-jamming ability.

Detailed Images

Technical Parameter

Laser source
10.6um CO2 glass tube
Laser power
RECI / WEIJU / YONGLI 80W / 100W / 150W
Laser Frequency
20-200KHZ
Galvanometer speed
<10m/s
Marking area
600*600mm / 800*800mm
3 axis Dynamic focus system
Feeltek
Software
LenMark
Optical lens
F-theta lens
Minimum Line Width
0.02mm
Minimum Character
0.3mm
Marking Depth
≤5mm (depend on materials)
Repeat Accuracy
±0.01mm
Dynamic Axial Respone Time
<4ms
Beam quality
M2:1.2~1.8
Support format
bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc.
Voltage
220V(±10%)/50Hz/30A
Cooling way
Water Chiller CW5000 / 5200
Machine power
3.2KW
Gross Weight
300KGS
Dimension
2100*1590*960mm

Samples
Application Industries
Machine is used for arts & crafts, leather products, glasses, clothing, bamboo and wood products industry, package, advertising decoration and architectural model.
Application Materials
Machine is suitable for almost all non-metal materials, including leather, rubber, wood board, bamboo products, organic glass, ceramic tile, plastics, marble, jade, crystal, cloth, etc.
